| Camera | Image Sensor | 1/2.8” 5.14Megapixel progressive CMOS |
|---|
| Image Pixel | 2880 x 1620 pixel |
|---|
| Electronic Shutter Speed | 1sec ~ 1/10,000sec |
|---|
| Min. Illumination | COLOR : 0.01 Lux@F1.6 , B/W : 0 Lux (IR on) |
|---|
| Illumination Distance | More than 20M |
|---|
| Illuminator Number | IR LED(2W) 2EA, WARM LED(2W) 2EA, RED LED : Alarm or Event |
|---|
| Lens | Lens Type | Fixed |
|---|
| Focal Length | 3.6mm, F1.6 |
|---|
| Field of View | H : 95˚ / V : 48˚ / D : 112˚ |
|---|
| Video | Video Compression | H.265 / H.264 / MJPEG |
|---|
| Video Frame Rate | Max. 30 fps |
|---|
| Function | Day/Night | Auto(CDS/CAM) / Day / Night(ICR) |
|---|
| BLC/HLC/WDR | Yes |
|---|
| Intelligence | Line Crossing, Region entrance/exiting, Area Intrusion |
|---|
| Thermal | Detector Type | IR array thermal sensor |
|---|
| Resolution | 32 x 24 pixel |
|---|
| Audio | Audio Compression | G.711, ACC |
|---|
| Speaker | Internal, 3W |
|---|
Network | Interface | RJ-45 (10/100 Base-T) | | Protocol | IPv4, TCP/IP, UDP, RTP, RTSP, RTMP, NTP, HTTP, HTTPS , DNS, DDNS, DHCP, FTP |
|---|
| Interoperability | ONVIF(Profile S) |
|---|
| User/Host | 10 |
|---|
Power | Power Supply | 12V DC / PoE (802.3af) | | Power Consumption | Max. 12W |
|---|
Environment | Operating Conditions | -20°C ~ 50°C | | Protection | IP66 |
|---|
Structure | Dimensions | Φ93.5mm x 279.8 mm | | Net Weight | 1.0kg |
|---|
